30mm Penetration Airport x-ray security equipment with high Resolution XLD-6550
Premium Products
30mm Penetration Airport x-ray security equipment with high Resolution XLD-6550
1
2
3
4
5
Place of Origin :Guangdong, China
Brand Name :sunleader
Model Number :XLD-6550
tunnel size :650(W)x500(H) mm
conveyor speed :0.1m/s
conveyor max load :100kg
Resolution :Diameter of 0.1mm metal wire
Penetration :30mm steel plate
Storage temperature :-20°C to 60°C
Operating temperature :0 °C to 45 °C
System power :220VAC (±10%) 50±3HZ
Power wastage :1.0KW(max)
Name :security equipment
Packaging Details :standard export wooden case.
Port :shenzhen
Supply Ability :500 Set/Sets per Month
Price :$9,500.00 - $12,000.00/sets
Contact Now
30mm Penetration Airport x-ray security equipment with high Resolution XLD-6550
Model
XLD-6550
Tunnel size:
650(W)x500(H) mm
Conveyor speed:
0.2m/s
Conveyor max load:
100kg
Single inspection dosage:
<1.5upGy
Wire resolution:
0.1mm metal line
Steel penetration:
30mm armor plate
Film safety:
for ISO 1600
Maximum leakage radiation:
<0.3ugy/H
Storage temperature:
-20°C to 60°C
Operating temperature:
0 °C to 45 °C
Relative humidity:
20 to 95% non-condensing
System power:
220VAC (±10%) 50±3HZ
Power wastage:
1.0KW(max)
Noise:
<65DB
Image performance system
X-ray sensor:1 Type photo-diode array detector, 12bit
Monitor:High resolution 17inch color led display
Color quality:24 bit real colors
Edge enhancement: object contour edge is more distinct
Super image enhancement:image detail is more distinct
High penetrate strength display:increase brightness of dark area in image to diplay object which is behind high absorption mass distinctly
Low penetrate strength display:increase brightness of image/decrease brightness of image
Image recurrence:display previous twenty images and process any one of them
Image restoration:restore image to initial status at the time of stopping conveyor
Image storing:real time store any image and process it in operation status
Multi-energy function
Multienergy color:display organic material for orange, display inorganic material for blue, and display mixture for green
High enery/low energy:switch to display tow energy type, high energy stands for metal etc, low energy stands for non metallic
Auxilitay function for drugs &explosives:help to detect such dangerous material as drugs&explosives ect
Audible&visible alarm:give sound and visible signal when confirming to condition
Main Advantages
Alarm by sounds&light:Alarm by sound and light when confirm to condition
Network interface:It can connect to local area network and support multi-terminal check baggage at same time.
Safty ray:Transmit ray under automatic control, avoiding any baggage missing.
Image monitoring for userfriendly:The monitor use fold, rotary system, operators, adjusts the monitor position willfully according to our own need, reduce wearily.
Simple operation by mouse:Without keyboard and work table, control by mouse, save space.
Turn off a key control:Turn off the machine only need one step, revolove the key then the equipment automatic secuirty close down and no need complex steps.
Eagle-eye:It can be expediently observing enlarged area.
Estimate malfunction by self:Automatic estimate malfunction and prompt message, helpful for maintenance
Certifications
FAQ
1. What is the minimum order quantity?
The MOQ is 1 set.
2. What is the lead time?
3-5days after T/T payment, for other products please contact us for details.
3. What is the payment term?
The payment term is T/T ,L/C before shipment.
4: How does your company and factory do regarding quality control?
Every products will be detected after producing and approved by ISO9001 and CE certificate.
30mm Penetration Airport x-ray security equipment with high Resolution XLD-6550 Images
